136 Seria Ultra-Bite

Stock	Order No	Legacy Code	d1	d2	d3	l1	l2	l3	Corner	Z
	83134	11F01_13600040300A02	3	6	2.95	50	9	13	Ch 0,20	4
*	83100	11F01_13600040300A01	3	6	2.95	57	9	13	Ch 0,20	4
	83136	11F01_13600040400A02	4	6	3.95	50	11	15	Ch 0,20	4
*	83102	11F01_13600040400A01	4	6	3.95	57	11	15	Ch 0,20	4
	83148	11F01_13600040470S01	4.70	6	-	50	13	-	Ch 0,13	4
	83146	11F01_13600040570S01	5.70	6	-	50	13	-	Ch 0,13	4
	83104	11F01_13600040500A01	5	6	4.95	57	14	17	Ch 0,20	4
*	83106	11F01_13600040600A01	6	6	-	57	15	-	Ch 0,20	4
*	83130	11F00_13600040600A01	6	6	-	57	15	-	-	4
	83144	11F01_13600040770S01	7.70	8	-	50	13	-	Ch 0,13	4
	83140	11F01_13600040800S01	8	8	-	64	13	-	Ch 0,13	4
*	83108	11F01_13600040800A01	8	8	-	64	20	-	Ch 0,20	4
	83150	11F01_13600040800X01	8	8	7.50	64	30	30	Ch 0,20	4
*	83128	11F00_13600040800A01	8	8	-	64	20	-	-	4
	83142	11F01_13600041000S02	10	10	-	72	23	-	Ch 0,13	4
*	83110	11F01_13600041000A01	10	10	-	72	22	-	Ch 0,25	4
*	83132	11F00_13600041000A01	10	10	-	72	22	-	-	4
*	83138	11F01_13600041000S01	10	10	-	80	32	-	Ch 0,40	4
*	83112	11F01_13600041200A01	12	12	-	73	29	-	Ch 0,25	4
*	83114	11F01_13600041200A02	12	12	-	82	29	-	Ch 0,25	4
	83116	11F01_13600041400A01	14	14	-	82	29	-	Ch 0,30	4
	83118	11F01_13600041600A01	16	16	-	93	34	-	Ch 0,30	4
	83120	11F01_13600041800A01	18	18	-	93	34	-	Ch 0,30	4
	83122	11F01_13600042000A01	20	20	-	105	40	-	Ch 0,40	4

Ø	ap=1.5Ø	ap=1Ø	ap=0.50Ø	ae=0.35Ø	ae=0.30Ø	ae=0.25Ø	ae=0.20Ø	ae=0.15Ø	ae=0.10Ø
3	0.004	0.006	0.008	0.010	0.012	0.016	0.020	0.030	0.042
4	0.007	0.009	0.013	0.016	0.020	0.025	0.030	0.038	0.049
5	0.010	0.013	0.017	0.020	0.025	0.031	0.036	0.046	0.058
6	0.014	0.018	0.022	0.026	0.030	0.037	0.044	0.050	0.062
8	0.020	0.025	0.029	0.034	0.040	0.048	0.056	0.064	0.073
10	0.026	0.030	0.038	0.042	0.050	0.059	0.067	0.076	0.088
12	0.035	0.042	0.053	0.060	0.070	0.080	0.092	0.102	0.115
16	0.042	0.060	0.082	0.100	0.110	0.120	0.130	0.138	0.150
20	0.050	0.065	0.085	0.100	0.110	0.120	0.130	0.138	0.150

Material	Frezare cu caneluri	Frezare Laterală	Terminați frezarea

	ap=1.0 - 0.5Ø	ap=1.5Ø / ae=0.35 - 0.20Ø	ap=1.5Ø / ae=0.20 - 0.10Ø
	Vc (m/min.)	Vc (m/min.)	Vc (m/min.)
AISI 304 - 416 - 420	50-70	70-90	80-100
AISI 316 - 440	45-70	55-80	60-90
17-4 PH 15-5 PH	45-70	55-80	60-90
Aliaj crom-cobalt Cr - Co Ajloys	30-50	35-55	40-70
Duplex F51	60-80	65-85	70-90
Super Duplex F55	60-80	65-85	70-90
HRSA Hastelloy	30-50	40-60	50-70
HRSA lncoinel 625	30-50	40-60	50-70
HRSA lncoinel 718	30-50	40-60	50-70
HRSA Nimonic	30-50	40-60	50-70
Titan	60-80	70-90	80-90
Aliaje de titan	60-80	70-90	80-90

Frezare (Ultra-Bite)
