| Steel |
|
|
| Stainless Steel |
|
|
| Hardened Steel ≤ 54 HRc |
|
|
| Hardened Steel > 54 HRc |
|
|
| Cast |
|
|
| Graphite |
|
|
| Non Ferrous Material |
|
|
| HRSA |
|
|
| Titanium |
|
Recommended Acceptable Not Recommended| Stock | Code | d1f8 | d2h6 | l1 | α (°) |
|---|---|---|---|---|---|
| KPAN01015 | 0.1 | 3 | 39 | 15 | |
| KPAN02015 | 0.2 | 3 | 39 | 15 | |
| KPAN03030 | 0.3 | 3 | 39 | 30 | |
| KPAN05015 | 0.5 | 3 | 39 | 15 | |
| KPAN07015 | 0.7 | 3 | 39 | 15 | |
| KPAN10015 | 1 | 3 | 39 | 15 | |
| KPAN01030 | 0.1 | 3 | 39 | 30 | |
| KPAN02030 | 0.2 | 3 | 39 | 30 | |
| KPAN05030 | 0.5 | 3 | 39 | 30 | |
| KPAN07030 | 0.7 | 3 | 39 | 30 | |
| KPAN10030 | 1 | 3 | 39 | 30 | |
| KPAN01045 | 0.1 | 3 | 39 | 45 | |
| KPAN02045 | 0.2 | 3 | 39 | 45 | |
| KPAN05045 | 0.5 | 3 | 39 | 45 | |
| KPAN07045 | 0.7 | 3 | 39 | 45 | |
| KPAN10045 | 1 | 3 | 39 | 45 |
