270 Mic-Cut Series

Order No	Code	d1h10	d2h5	d3	l1	l2	l3	Corner	Z
86100	11F02_27000020050A01	0.50	4	0.45	51	0.50	2	R 0,25	2
86102	11F02_27000020050A02	0.50	4	0.45	51	0.50	3	R 0,25	2
86104	11F02_27000020050A03	0.50	4	0.45	51	0.50	4	R 0,25	2
86106	11F02_27000020060A01	0.60	4	0.55	51	0.60	2	R 0,30	2
86108	11F02_27000020060A02	0.60	4	0.55	51	0.60	4	R 0,30	2
86110	11F02_27000020060A03	0.60	4	0.55	51	0.60	6	R 0,30	2
86112	11F02_27000020080A01	0.80	4	0.75	51	0.80	2	R 0,40	2
86114	11F02_27000020080A02	0.80	4	0.75	51	0.80	4	R 0,40	2
86116	11F02_27000020100A01	1	4	0.94	51	1	4	R 0,50	2
86118	11F02_27000020100A02	1	4	0.94	51	1	6	R 0,50	2
86120	11F02_27000020100A03	1	4	0.94	51	1	8	R 0,50	2
86122	11F02_27000020100A04	1	4	0.94	51	1	10	R 0,50	2
86124	11F02_27000020100A05	1	4	0.94	51	1	12	R 0,50	2
86126	11F02_27000020150A01	1.50	4	1.40	51	1.50	4	R 0,75	2
86128	11F02_27000020150A02	1.50	4	1.40	51	1.50	6	R 0,75	2
86130	11F02_27000020150A03	1.50	4	1.40	51	1.50	8	R 0,75	2
86132	11F02_27000020150A04	1.50	4	1.40	51	1.50	10	R 0,75	2
86134	11F02_27000020150A05	1.50	4	1.40	51	1.50	12	R 0,75	2
86136	11F02_27000020200A01	2	4	1.90	51	2	4	R 1,00	2
86138	11F02_27000020200A02	2	4	1.90	51	2	6	R 1,00	2
86140	11F02_27000020200A03	2	4	1.90	51	2	8	R 1,00	2
86142	11F02_27000020200A04	2	4	1.90	51	2	10	R 1,00	2
86144	11F02_27000020200A05	2	4	1.90	51	2	12	R 1,00	2
86146	11F02_27000020250A01	2.50	4	2.40	51	2.50	6	R 1,25	2
86148	11F02_27000020250A02	2.50	4	2.40	51	2.50	8	R 1,25	2
86150	11F02_27000020250A03	2.50	4	2.40	51	2.50	10	R 1,25	2
86152	11F02_27000020250A04	2.50	4	2.40	51	2.50	12	R 1,25	2

You can use the “KarcanEYE” application to access the machining data for this series based on the material and operational details. More Information

	Steel
	Stainless Steel
	Hardened Steel ≤ 54 HRc
	Hardened Steel > 54 HRc
	Cast
	Graphite
	Non Ferrous Material
	HRSA
	Titanium

Mic Cut

270 Series Endmill

270 Mic-Cut Series
